Apiezon Grease
Wax for permanent sealed joints at room temperatures
for low to medium vacuum range
891-2 : Apiezon Type L, 25g tube, each
#891-104 : Apiezon Type L, 50g tube, each
#891-144 : Apiezon Type L, Bulk 4kg, each
#891-1 : Apiezon Type M, 25g tube, each
#891-12 : Apiezon Type M, 100g tube, each
#891-101 : Apiezon Type M, Bulk 4 kg, each
#891-4 : Apiezon Type N, 25g tube, each
#891-120 : Apiezon Type T, 25g tube, each
#891-3 : Apiezon Type H, 25g tube, each
#891-152 : Apiezon AP100, 50g tube, each
#891-160 : Apiezon AP101, 50g tube, each
#891-162 : Apiezon AP101, Bulk 4 kg, each
#891-75 : Apiezon Q Sealing Compound, 1kg, each
#891-81 : Apiezon W Wax, 100gr, each
#891-85 : Apiezon W Wax, 500gr, each
Main Properties of Apiezon® Greases
| Typical Properties | AP101 | AP100 | H Grease | L Grease | M Grease | N Grease | T Grease | Q Sealant | W Wax |
| Main Areas of Application | General Purpose | Lubricating | High Temperature |
High Vacuum |
General Vacuum |
Cryogenic | Medium Temperature |
Sealing | Sealing |
| Typical Working Temperature Range, °C |
-40 to 180 | 10 to 30 | -10 to 240 | 10 to 30 | 10 to 30 | -269 to 30 | 10 to 120 | -10 to 30 | -1 to 75 |
| Melting Point- ASTM.D 566, °C |
>200 | 47 | >250 | 47 | 44 | 43 | 125 | 40 to 50 | 80 to 90 |
| Vapor Pressure, Torr @20°C |
<1.0 x 10-5 | <7.0 x 10-11 | <1.7 x 10-9 | <7.0 x 10-11 | <1.7 x 10-9 | <6.0 x 10-10 | <4.6 x 10-9 | 1 x 10-10 | <4.5 x 10-9 |
| Relative Density @20°C | 0.981 | 1.042 | 0.918 | 0.896 | 0.894 | 0.911 | 0.912 | - | - |
| Resistant to Radiation | N/R | N/R | N/R | Yes | Yes | N/R | N/R | N/R | N/R |
| Lubricity 4 Ball Test ASTM.D 2763 (IP239), kg | 450 | 450 | 250 | 150 | 140 | 150 | 250 | N/A | N/A |
| Outgassing Characteristics- ASTM.E 595-90 TML/ CVCM |
N/A N/A |
<1% |
<1% |
<1% |
N/A |
<1% |
N/A |
N/A | N/A N/A |
| Coefficient of expansion per °C over 20-30°C | 0.00066 | N/A | 0.00077 | 0.00076 | 0.00075 | 0.00072 | 0.00073 | N/A | N/A |
| Thermal conductivity @20 °C, w/m °C | N/A | N/A | 0.216 | 0.202 | 0.192 | 0.230 | 0.176 | N/A | 0.189 |
| Electrical strength, V/mil (0."001) | N/A | N/A | 800 | 730 | 850 | 820 | 730 | N/A | N/A |
