Teflon Cleaning (Etching) Jig



MS - N (10*10mm,20mm*20mm , 30mm*30mm)

PFA Carrier W30*D40*20H*120L(8Hole)

                                      MS- M (PFA 30*30mm,40*40mm,50*50mm- Square Jig & Handle )

                                  1)W76*D61*31H 2) 12 Slot-4.0 mm  간격 3) Handle :1) 157 mm  2) 250mm







                                           MS-MF  (30*30mm,40*40mm,50*50mm,100*100- Square Jig)



                                 MS-MFA (30*30mm,40*40mm,50*50mm,100*100- Square Jig)



MS-MFB(30*30mm,40*40mm,25*50,50*50mm,100*100- Square Jig)

 MS-DB  (10mm*10,15*15,20*20mm Size: 30W*40L*20H)



MS-DC (10mm*10mm,20mm*20mm) ( PTFE: 30W*30D*15H*5Hole*2)



  MS-AS(OD:30*30*20H-5*7*13H*4Hole)



 MS-DRS (OD:40*40*20H-5Hole)



  MS-D  (R 50mm*20H*3mm*10Hole)

# Samlpe Home 1mm,1.5mm ,2mm,2.5mm



                                     MS-DA (20mm*20mm , 30mm*30mm, 40mm*40mm)

                                             # Samlpe Home 1mm,1.5mm ,2mm,2.5mm



                                                  MS - DT (20mm*20mm , 30mm*30mm)

                                                 # Samlpe Home 1mm,1.5mm ,2mm,2.5mm



                                             MS-A



                                                                 MS - B



                                                                          MS-C



                                                                  MS - E

                                                             MS-H 2"3"4"5"6"



      MS-G





                                                      MS- S  2".3"Wafer etching Jig



                                              MS -T 4". 5". 6" Wafer etching Jig



                                                      MS-TA 4". 5". 6" 8" Wafer etching Jig



   MS-TAB 4". 5". 6" 8" Wafer etching Jig



                                                                MS -U 2,3,4,5,6,8 Inch Wafer etching Jig

 MS -UR 2,3,4,5,6,8 Inch Wafer etching Jig



MS - URA 2,3,4,5,6,8 Inch Wafer etching Jig



                                MS - K 2.3.4.5.6 Inch Wafer Jig

                                                        MS-KK 4.5.6.8 Inch Wafer Jig

                             MS-KKK 5,6,8,10 Inch Wafer Jig



MS-KW ( 2", 3", 4" )Wafer Jig





MS-WP(Wafer 단면, 양면)







                                MS-W 2" Wafer Jig

                                                    MS-WA 2, 4, 6,8 Inch Wafer Jig



                                                    MS-WAH   2, 4, 6,8 Inch Wafer  Jig



MS - WA - HS





MS-WA-D Dipper Basket(D10-0315)

Used to clean or etch small pieces Hook on end of handle Contains 100 openings Fits in 400 ml (13.5 oz) and larger beakers Opening size: 5.6mm sq. (0.22") Inside dimensions: 63mm dia. x 51mm (2.5" x 2.0") Overall size: 68mm dia. x 235mm (2.7" x 9.3") Lead time: eight weeks

                                                           MS- SR



                                                                     MS-SRA



                                   MS-X  PFA Wafer Carrier &Handle 2,4,6,8 Inch

                                           (50*50mm,100*100mm,156*156mm)







MS-XS  PVDF 156mm *156mm Solar Wafer Carrier

label

Specifications   Capacity: 25 Overall Size: 186mm (7.32in) x 144mm (5.67in) x 175mm (6.89in) Material: Polyvinylidene Fluoride (PVDF) Material Description: A specialty plastic material in the fluoropolymer family.  It is used in applications requiring high purity, strength, and resistance to solvents, acids, and bases up to temperatures of approximately 150C.   Features and Benefits   Accommodates 156mm square or pseudo square solar wafers. High Profile Solid end Wall H Shaped end wall Wash slots in side walls Individually packaged and sold as singles

MS-SP 5" 6"8" 150*150, 200*200   Solar Cell &Glass Etching Jig





MS-SPS 4" 5" 6"8" 150*150, 200*200  Solar Cell &Glass Etching Jig

MS-SPA 2-8" Wafer & Solar Cell &Glass Etching Jig



MS-SPC 2-8" Wafer & Solar Cell &Glass Etching Jig(150*150 200*200)



MS-SPB 2-6" Wafer & Solar Cell &Glass Etching Jig



MS-SPSS 5" 6"8" 150*150, 200*200  Solar Cell &Glass Etching Jig



Solar Wafer Etching Carrier MS-SWD



                              Solar Wafer Etching Carrier MS-SWE 5" 6" 8" 150*150, 200*200 Solar Cell &Glass Etching Jig



MS-SPST 5" 6"8" 150*150, 200*200  Solar Cell &Glass Etching Jig



MS-Q  2",3",4",5",6' Quartz Wafer Jig

모든 제품의  크기는 원하는 사이즈로 제작이 가능합니다..

         MS - U  Dippers

• Holds one wafer or one square plate
• Slot has "V" bottom
• Clip on handle slides down to hold substrates in place
• Lead time: eight weeks



D15

D14

D11



Part Number	Wafer Size	Square Plate Size	Maximum Thickness	Dipper Length	Material
D15-0215	125mm to 200mm (5" to 8")	114mm to 203mm (4.5" to 8.0")	6.4mm (0.25")	480mm (18.9")	PFA
D14-0215	57mm to 125mm (2.25" to 5")	50mm to 153mm (2.0" to 6.0")	3.0mm (0.12")	265mm (10.4")	PFA
D11-0215	57mm and smaller (2.25" and smaller)	51mm and smaller (2.0" and smaller)	1.5mm (0.06")	210mm (8.3")	PFA





모든 제품의  크기는 원하는 사이즈로 제작이 가능합니다..





제품에 대한 문의사항이 있으시면 아래 e-mail, 전화 문의 바랍니다.

MSE : 02-2275-9510     팩스 : 02-2278-5446

msescy@hanmail.net   http://semims.com

















MS - F 2,3,4" Wafer jig
